LONG GER INDUSTRY CO., LTD.

Max. drilling capacity in wood: Ø15 – Ø20 mm
Custom hole spacing available.
Max. speed: 6000 RPM
Suitable for drilling boards, solid wood, furniture components, toys, and composite materials.
Compatible with standard drilling machines or automated drilling equipment.

MODEL	A	B	C	D	E	F	G	H	L1	L2	X	Y	PH	Max capacity	Spindle Type	Weight(kg)
3L-20	10	10	28	55	54	78	3	24	62	90	46	74	20mmx3	Φ15	m8x1.25,m10x1.5	2.9
3L-22	10	10	28	55	54	78	3	24	62	90	46	74	22mmx3	Φ15	m8x1.25,m10x1.5	2.9
3L-25	10	10	28	55	54	78	3	26	62	90	46	74	25mmx3	Φ15	m8x1.25,m10x1.5	2.9
3L-30	10	10	28	55	54	78	3	24	62	120	46	88.8	30mmx3	Φ20	m8x1.25,m10x1.5	2.5
3L-32	10	10	28	55	54	78	3	24	62	120	46	88.8	32mmx3	Φ20	m8x1.25,m10x1.5	2.5
3L-38	10	10	28	55	54	78	3	24	62	145	46	88.8	38mmx3	Φ20	m8x1.25,m10x1.5	3.6
5L-20	10	10	28	55	54	78	3	24	62	120	46	88.8	20mmx5	Φ15	m8x1.25,m10x1.5	2.4
5L-22	10	10	28	55	54	78	3	24	62	120	46	88.8	22mmx5	Φ15	m8x1.25,m10x1.5	2.4
5L-25	10	10	28	55	54	78	3	26	62	145	46	88.8	25mmx5	Φ15	m8x1.25,m10x1.5	3.8
5L-30	10	10	28	55	54	78	3	24	62	176	46	88.8	30mmx5	Φ20	m8x1.25,m10x1.5	3.2
5L-32	10	10	28	55	54	78	3	24	62	176	46	88.8	32mmx5	Φ20	m8x1.25,m10x1.5	3.2
7L-32	10	10	28	55	54	78	3	24	62	245	46	88.8	32mmx7	Φ15	m8x1.25,m10x1.5	4.0
9L-32	10	10	28	55	54	78	3	24	62	308	46	88.8	32mmx9	Φ15	m8x1.25,m10x1.5	4.5
11L-32	10	10	28	55	54	78	3	24	62	365	46	88.8	32mmx11	Φ15	m8x1.25,m10x1.5	5.0
15L-32	10	10	28	55	54	78	3	24	62	495	46	88.8	32mmx15	Φ15	m8x1.25,m10x1.5	6.8
21L-32	10	10	28	55	54	78	3	24	62	685	46	88.8	32mmx21	Φ15	m8x1.25,m10x1.5	8.5
