Features
- Max. drilling capacity in wood: Ø8 – Ø15 mm
- Fixed hole spacing available in various specifications.
- Max. speed: 6000 RPM
- Suitable for drilling boards, solid wood, furniture components, toys, and composite materials.
- Compatible with standard drilling machines or automated drilling equipment.
| MODEL | A | B | C | D | E | F | G | H | L | X | Y | PH1 | PH2 | PH3 | PH4 | PH5 | Max capacity | Spindle Type | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5B-16 | 10 | 10 | 28 | 55 | 53 | 77 | 3 | 24 | 83 | 45.5 | 45.5 | 16 | 20 | 25 | 32 | 40 | Φ8 | m8x1.25,m10x1.5 | 2.5 |
| 5B-17 | 10 | 10 | 28 | 55 | 53 | 77 | 3 | 24 | 83 | 45.5 | 45.5 | 17 | 22 | 32 | 34 | 44 | Φ8 | m8x1.25,m10x1.5 | 2.5 |
| 5B-20 | 10 | 10 | 28 | 55 | 53 | 77 | 3 | 24 | 93 | 49.5 | 49.5 | 20 | 24 | 28 | 40 | 48 | Φ15 | m8x1.25,m10x1.5 | 3.2 |
| 5B-32 | 10 | 10 | 28 | 55 | 53 | 77 | 3 | 24 | 93 | 49.5 | 49.5 | 20 | 25 | 32 | 40 | 50 | Φ15 | m8x1.25,m10x1.5 | 3.2 |
| 5B-25 | 10 | 10 | 28 | 55 | 60 | 75 | 3 | 31 | 108 | 64 | 64 | 1" | 1 1/4" | 1/2" | 2 | 2 1/2" | Φ15 | m8x1.25,m10x1.5 | 4.6 |
