Features
- Adjustable spindle spacing: PCD Ø34 – Ø206 mm
- Max. drilling capacity in wood: Ø10 – Ø50 mm
- Max. speed: 6000 RPM
- Designed for square hole patterns.
- Graduated adjustment scale for precise spindle spacing adjustment and accurate hole positioning.
- Suitable for boards, solid wood, furniture components, toys, and composite materials.
- Compatible with standard drilling machines and automated drilling equipment.
| Model | A | B | C | D | E | G | H | L1 | L | X | Y | Min | Max | Max capacity | Spindle Type | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4C-W34 | 10 | 10 | 28 | 55 | 121 | 3 | 15 | 115 | 140 | 70.7 | 70.7 | Ø34 | Ø94 | Ø10 | m8x1.25,m10x1.5 | 4.8 |
| 4C-W42 | 10 | 10 | 28 | 55 | 145 | 3 | 15 | 117 | 132 | 70.7 | 70.7 | Ø42 | Ø114 | Ø15 | m8x1.25,m10x1.5 | 6.3 |
| 4C-W48 | 10 | 10 | 28 | 55 | 170 | 3 | 15 | 109 | 134 | 70.7 | 70.7 | Ø48 | Ø132 | Ø20 | m8x1.25,m10x1.5 | 7.7 |
| 4C-W58 | 10 | 10 | 28 | 55 | 192 | 3 | 15 | 118.5 | 143.5 | 70.7 | 70.7 | Ø58 | Ø156 | Ø30 | m8x1.25,m10x1.5 | 10.4 |
| 4C-W78 | 10 | 10 | 28 | 80 | 260 | 3 | 15 | 145 | 170 | 70.7 | 70.7 | Ø78 | Ø206 | Ø50 | m8x1.25,m10x1.5 | 19.5 |
| 5C-W20 | 10 | 10 | 28 | 55 | 145 | 3 | 15 | 117 | 132 | 70.7 | 70.7 | Ø40 | Ø112 | Ø15 | m8x1.25,m10x1.5 | 6.5 |
