Features
- Designed for equilateral triangular hole patterns.
- Adjustable spindle spacing: PCD Ø22 – Ø180 mm
- Drilling capacity: Ø1 – Ø14 mm
- Reversible spindle rotation for drilling and tapping operations.
- Suitable for automotive and motorcycle parts, bicycles, home appliance components, electronics, furniture manufacturing, and aerospace industries, meeting drilling and tapping requirements for various workpiece materials.
| Model | A | B | C | D | E | G | H | L1 | L | X | Y | Min | Max | Max capacity | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 33C-T5 | 10 | 10 | 28 | 55 | 110 | 3 | 15 | 116 | 153 | 72.7 | 72.7 | Ø22 | Ø82 | Ø5 | 4.6 |
| 33C-T7 | 10 | 10 | 28 | 55 | 126 | 3 | 15 | 107 | 149 | 86.8 | 86.8 | Ø28 | Ø100 | Ø7 | 5.5 |
| 33C-T10 | 10 | 10 | 28 | 55 | 150 | 3 | 15 | 111 | 156 | 86.8 | 86.8 | Ø32 | Ø116 | Ø10 | 7.3 |
| 33C-T12 | 10 | 10 | 28 | 55 | 177 | 3 | 15 | 119 | 169 | 86.8 | 86.8 | Ø38 | Ø138 | Ø12 | 10.5 |
| 33C-T16 | 10 | 10 | 28 | 62 | 225 | 3 | 15 | 138 | 198 | 86.8 | 86.8 | Ø52 | Ø180 | Ø14 | 15.5 |
