Features
- Designed for linear hole patterns with equal spacing.
- Adjustable spindle spacing: 14 – 200 mm
- Drilling capacity: Ø1 – Ø14 mm
- Reversible spindle rotation for drilling and tapping operations.
- Suitable for automotive and motorcycle parts, bicycles, home appliance components, electronics, furniture manufacturing, and aerospace industries, meeting drilling and tapping requirements for various workpiece materials.
| Model | A | B | C | D | E | F | G | H | LI | L | X | Y | Min | Max | Max Capacity | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3C-T5 | 10 | 10 | 28 | 55 | 121 | 58 | 3 | 18 | 107 | 142 | 40 | 73.8 | 14 | 88 | Ø5 | 3.7 |
| 3C-T7 | 10 | 10 | 28 | 55 | 150 | 71 | 3 | 17 | 112 | 154 | 46 | 88.8 | 20 | 112 | Ø7 | 4.0 |
| 3C-T10 | 10 | 10 | 28 | 55 | 162 | 76 | 3 | 17 | 114 | 159 | 46 | 88.8 | 22 | 128 | Ø10 | 6.0 |
| 3C-T12 | 10 | 10 | 28 | 55 | 191 | 92 | 3 | 15 | 118.5 | 168.5 | 46 | 88.8 | 26 | 152 | Ø12 | 8.7 |
| 3C-T16 | 10 | 10 | 28 | 72 | 251 | 114 | 3 | 15 | 141 | 201 | 70.7 | 70.7 | 36 | 200 | Ø14 | 14.7 |
