Features
- Adjustable spindle spacing: 13.5 – 164 mm
- Drilling capacity: Ø1 – Ø14 mm
- Reversible spindle rotation for drilling and tapping operations.
- Suitable for automotive and motorcycle parts, bicycles, home appliance components, electronics, furniture manufacturing, and aerospace industries, meeting drilling and tapping requirements for various workpiece materials.
| Model | A | B | C | D | E | F | G | H | LI | L | X | Y | Min | Max | Max Capacity | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2C-T5 | 10 | 10 | 28 | 55 | 106.5 | 57 | 3 | 15 | 115 | 150.5 | 40 | 73.8 | 13.5 | 73.5 | Ø5 | 3.6 |
| 2C-T7 | 10 | 10 | 28 | 55 | 127.5 | 67 | 3 | 15 | 112 | 154 | 46 | 88.8 | 18 | 90 | Ø7 | 4.5 |
| 2C-T8 | 10 | 10 | 28 | 55 | 191 | 109 | 3 | 16 | 120 | 165 | 70.7 | 70.7 | 25 | 151 | Ø6 | 8.7 |
| 2C-T10 | 10 | 10 | 28 | 55 | 143 | 82 | 3 | 15 | 114 | 159 | 46 | 88.8 | 22 | 106 | Ø10 | 5.5 |
| 2C-T12 | 10 | 10 | 28 | 55 | 166 | 92 | 3 | 16 | 120 | 170 | 46 | 88.8 | 26 | 126 | Ø12 | 7.3 |
| 2C-T16 | 10 | 10 | 28 | 55 | 211 | 114 | 3 | 16 | 138 | 198 | 70.7 | 70.7 | 36 | 164 | Ø14 | 10.7 |
