Features
- Adjustable spindle spacing: PCD Ø22 – Ø180 mm
- Max. drilling capacity in wood: Ø10 – Ø50 mm
- Max. speed: 6000 RPM
- Designed for equilateral triangular hole patterns.
- Graduated adjustment scale for precise spindle spacing adjustment and accurate hole positioning.
- Suitable for boards, solid wood, furniture components, toys, and composite materials.
- Compatible with standard drilling machines and automated drilling equipment.
| Model | A | B | C | D | E | G | H | L1 | L | X | Y | Min | Max | Max capacity | Spindle Type | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 33C-W22 | 10 | 10 | 28 | 55 | 110 | 3 | 15 | 116 | 143 | 72.7 | 72.7 | Ø22 | Ø82 | Ø10 | m8x1.25,m10x1.5 | 3.7 |
| 33C-W28 | 10 | 10 | 28 | 55 | 126 | 3 | 15 | 107 | 132 | 86.8 | 86.8 | Ø28 | Ø100 | Ø15 | m8x1.25,m10x1.5 | 4.7 |
| 33C-W32 | 10 | 10 | 28 | 55 | 150 | 3 | 15 | 111 | 136 | 86.8 | 86.8 | Ø32 | Ø116 | Ø20 | m8x1.25,m10x1.5 | 6.0 |
| 33C-W38 | 10 | 10 | 28 | 55 | 177 | 3 | 15 | 119 | 144 | 86.8 | 86.8 | Ø38 | Ø138 | Ø30 | m8x1.25,m10x1.5 | 8.8 |
| 33C-W52 | 10 | 10 | 28 | 62 | 225 | 3 | 15 | 138 | 163 | 86.8 | 86.8 | Ø52 | Ø180 | Ø50 | m8x1.25,m10x1.5 | 13.8 |
